3PCS Body Forge Steel Ball Valve
3PCS Body Forge Steel Ball Valve
800LB,1500LB,2500LB
800LB,1500LB,2500LB
| 3PC Body Forge Steel Floating Ball Valve : NPT, SW, BW | ||
| Features | Specifications | |
| Size: 1/2"~2" | Design | ASME 16.34/BS 5351 |
| Class: 800LB,1500LB,2500LB | Face to Face | ASME B16.10 |
| 3 Pieces,Forge Steel Body | End to End | ASME B16.10 |
| Floating Ball, Full & Reduced Bore | NPT | ASME B1.20.1 |
| Anti-Static Device | BW&SW End | ASME B16.25 |
| Blow-out Proof Stem | Test | API 598/ BS 6755 |
| Fire Safe Design | Fire Safe Test | API 607/API 6FA |
| Low Emission | Special | NACE MR-01-7 |
| No. | Part | A105/304 | A105/316 |
| 1 | Adapter | ASTM A105 | ASTM A105 |
| 2 | Body Bolt | ASTM A193-B7 | ASTM A193-B7M |
| 3 | Spring Washer | Carbon Steel | Carbon Steel |
| 4 | Body Nut | ASTM A194-2H | ASTM A194-2HM |
| 5 | Body | ASTM A105 | ASTM A105 |
| 6 | Seat | PTFE | PTFE |
| 7 | Ball | ASTM A182-F304 | ASTM A182-316 |
| 8 | Stem | ASTM A276-304 | ASTM A276-316 |
| 9 | Thrust Washer | PTFE | PTFE |
| 10 | ‘Stem Packing | PTFE | PTFE |
| 11 | Gland | ASTM A276-410 | ASTM A276-410 |
| 12 | Stop Plate | Carbon Steel | Carbon Steel |
| 13 | Stop Pin | Carbon Steel | Carbon Steel |
| 14 | Spring Washer | Carbon Steel | Carbon Steel |
| 15 | Lever Nut | ASTM A194-2H | ASTM A194-2H |
| 16 | Lever | Carbon Steel | Carbon Steel |
| 17 | Antistatic Spring | Stainless Steel | Stainless Steel |
| 18 | Steel ball | Stainless Steel | Stainless Steel |
